| FICHA TECNICA |
| Engine |
|
| Engine Type: |
Single cylinder, air-cooled, Four-stroke |
| Displacement (ml): |
125 |
| Bore X Stroke (mm): |
56.5×49.5 |
| Compression Ratio: |
9.0:1 |
| Max. Power (kw/r/min) |
7.2/8500 |
| Max. Torque (N.m/r/min): |
10/7500 |
| Max. Speed (Km/h): |
≥85 |
| Lubrication: |
Pressure, splash (SE 15W-40) |
| Clutch Type: |
Multiplate wet clutch |
| Ignition: |
C.D.I |
| Starting System: |
Electric/Kick start |
| Transmission System: |
Chain drive |
| CHASSIS |
|
| Front Suspension: |
Hydraulic pressure and spring type |
| Rear Suspension: |
Hydraulic pressure and spring type |
| Front Wheel: |
Aluminium rim |
| Rear Wheel: |
Aluminium rim |
| Chassis structure: |
Rhombic tube plate |
| Front Brake: |
Disc Brake |
| Rear Brake: |
Drum Brake |
| Front Tire: |
2.5-18 |
| Rear Tire: |
2.75-18 |
| Muffler： |
baking finish muffler with chromed cover |
| Steering Head Angle: |
《48° |
| Battery: |
12V 6.5Ah |
| DIMENSIONS |
|
| L X W X H (mm): |
1920×715×1015 |
| Seat Height (mm): |
790 |
| Wheelbase (mm): |
1220 |
| Min. Ground Clearance (mm): |
160 |
| Max. Permissionable Weight (kg): |
150 |
| Rider Capacity: |
2 Persons |
| Dry. Weigth (kg): |
106 |
| Engine Oil (L): |
1.1 |
| Fuel Tank Capacity (L): |
13.3 |
